Mixer System
Drive motor: 50 HP (37 kW), 6 pole, max ~1100 rpm
Motor brand: Titan/Yuema – Ex China
Voltage: 380 V, 3 phase, 50 Hz
Inverter: LG LS Type S 50 HP (37 kW) – Ex Korea
Mixing Shaft & Disc
Shaft: Ø 65 mm SUS 304
Blade: Ø 400 mm, 4 mm thick Dissolver blade, SUS 304
Frame Structure
Main & side frame: approx. 2450 mm x 500 mm (thickness: 12 mm; 5 mm), material: Mild Steel SS-400
Finishing: Epoxy coating
Lifting System
Single acting hydraulic cylinder
Lifting cylinder: Ø 10” MS hard chrome
Casing cylinder: Ø 8” MS sch 40 – epoxy coated
Stroke: 1,400 mm
Power pack: 2 HP, ~1450 rpm, 4 pole, 380 V, 3 phase, 50 Hz, Titan/Yuema – Ex China
Electrical System
Integrated standard control panel, including:
Digital RPM + Potentiometer
Analog Amperemeter
ON/OFF & UP/DOWN push buttons
Emergency Stop Button
MCCB, Overload Relay, Chint Contactor
LG LS 50 HP inverter
3-meter power cable + 4-PIN 32A industrial plug
* We offer flexible specifications that can be modified to meet your industry’s specific needs
Many of our customers refer to this product as the HSD Mixer RST due to its consistent performance and reliable after-sales support.
Looking for a Production Scale or lab-scale HSD Mixer?
We also offer various capacity options.
Contact our team today for consultation and details.
